Model |
3SJ-G1100 |
3SJ-G1300 |
3SJ-G1700 |
3SJ-G2200 |
|
Screw diameter |
Φ50mm×3 |
Φ50mm×3 |
Φ55mm×2+60mm |
Φ65mm×2+70mm |
|
L/D ratio |
30:1 |
30:1 |
30:1 |
30:1 |
|
Output capacity |
60-120kg/h |
100-150kg/h |
150-220kg/h |
180-300kg/h |
|
Film width |
300-1000mm |
400-1200mm |
500-1500mm |
1000-2000mm |
|
Film thickness |
0.01-0.1mm |
0.01-0.1mm |
0.01-0.1mm |
0.01-0.1mm |
|
Main motor |
18.5KW×3 |
18.5KW×3 |
22KW×2+30KW |
37KW×2+45KW |
|
Total power |
120KW |
125KW |
150KW |
250KW |
|
Voltage |
380V, 50-60HZ, 3Phase |
|||
|
Die head |
Φ220mm |
Φ280mm |
Φ400mm |
Φ500mm |
|
Gross weight |
6500KG |
8500KG |
9500KG |
11000KG |
|
Dimension |
8.5×5.5×7.5M |
8.5×6×8M |
9.0×6.5×8.8M |
9.0×6.5×9M |
